Discover the superior quality and performance of the RTK Regeltechnik 097023-010 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 097023-010 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 097023-010 :
At Onrion LLC , we offer the 097023-010 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 097023-010 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | 097023-010 |
Description | Motorized Control Valve |
Internal code | ONR4071664 |
Technical specification | series MV 5274 three-way design for mixing application, shortened B-flange nominal diameter DN 80, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: bellows seal with safety stuffing box PTFE/white characteristic / flow direction: linear / - mixing cone, metal sealing kvs-value = 95 m3/h, stroke 25 mm seat diameter 80 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 350 °C Electric actuator - type REact 30E-028 actuating force 3 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.28 mm/s, stroke 25 mm protection rating IP 65 - additional limit switches (2 off) NOTE: original unit MV5274 DN80 PN16 KV95 STK25 SEAT80 + ST5112-32 230VAC 0.26mm/s |
