Discover the superior quality and performance of the Leser 4332.4174 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4332.4174 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4332.4174 :
At Onrion LLC , we offer the 4332.4174 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 4332.4174 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leser products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Leser |
| Product | 4332.4174 |
| Description | Modulated Action Safety Valve |
| Internal code | ONR4273469 |
| Custom code | 84814010 |
| Technical specification | Technical specification: Order code output, line 1: K7TM33MB1K4XH03K3IP2AJ36X00H88 Order code output, line 2: H84H15H47H22L8JL64L49H01 Housing material: (H22) Housing made of material 1.0619 (GP240GH) (with triple certification: WCB,WCC,1.0619) Nominal diameter inlet DN 40 Nominal diameter outlet DN 40 d0 (ASME-DIN) [mm] 23.0 Discharge coefficient D/G: 0.38 Flow coefficient F: 0.25 Flange pressure rating inlet (H47) PN 40 according to DIN EN 1092 Flange pressure rating outlet (H15) PN 40 according to DIN EN 1092 Flange sealing surface inlet: (H84) Form B1 (rough) according to DIN EN 1092 Flange sealing surface exit: (H88) Form B1 (rough) according to DIN EN 1092 Response pressure: 30.00 Pressure unit: bar-g Response pressure [bar-g] 30.00 Response pressure in psi-g: 435.11 Cold setting pressure [bar-g] 30.00 Cold set pressure [psi-g] 435.11 Operating temperature: 20 Temperature unit: °C - Celsius Operating temperature [°C] 20.00 Operating temperature in °F: 68 Plate, metallic / material: (L49) made of material: 1.4122 Sealing ring material: (MB1) Sealing ring made of graphite/1.4401 Spring material (X00) Standard material Spring hood material: (J36) 0.7043 (GGG 40.3) Guide disk material: (K3I) Guide disk material: 1.4104/ 430F Spindle material (K4X) Spindle material: 1.4021 Pressure screw material: (K7T) 1.4104/ 430F + PTFE/ glass Ventilation / cap material: (K8W) Ventilation / cap material: 0.7040/ 60-40-18 Stud screws Wst. Pos. 55 (L8J) Material of stud screws item 55: 1.7225/ SA-193 B7/ SA-320 L7 Hexagon nuts Wst. Pos. 56 (L9J) Material of hexagon nuts item 56: 1.7225 / SA-194 size 7 / SA-320 7L Blocking screw material: (MB5) Coloring: (P2A) Decrease: (M33) Proof of testing of the setting pressure (TRB 513 4.2, TRD 504 3.3.4): EN 10204-3.2 (TÜV Nord) Material quality certificate for: (H01) Housing – position 1 with material quality certificate 3.1 according to DIN EN 10204 Documentation: (H03) LESER CGA Certificate for Global Application Inspection certificate 3.1 according to DIN EN 10204 |
