Discover the superior quality and performance of the Warex 3006.GS (DKZ 103 GS) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 3006.GS (DKZ 103 GS) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 3006.GS (DKZ 103 GS) :
At Onrion LLC , we offer the 3006.GS (DKZ 103 GS) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 3006.GS (DKZ 103 GS) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Warex |
| Product | 3006.GS (DKZ 103 GS) |
| Description | butterfly valve |
| Internal code | ONR4449270 |
| Technical specification | for medium: powder coating Property: free-flowing, chemically neutral, not prone to caking Working pressure: pressureless Max. permissible operating pressure: pressureless (Ps) MAWP (Note: MAWP = Ausl. print) Operating temp.: 0°C to +60°C (Ts) MAWT Mod -Temp.: 0°C to +50°C (Ta) Explosion protection: II 1/3 D Ex h IIIC T 85°C Da/Dc X Evaluation of butterfly valves according to PED 2014/68/EU Diagram 7, certified module A2. The valves are not subject to conformity assessment. - Silicone-free design - ====================== Butterfly valve, type: DKZ 103 <GS> for clamping between flanges according to EN 1092, PN 10 Execution with type examination on Pressure surge resistance and ignition failure resistance up to 10 bar - according to Type examination BVS 19 ATEX H035X - as device can be used for KST values < 500 bar m/sec Silumin housing Valve housing with connection for earthing Sealing collar made of Buna CB conductive replaceable in the housing, flap disc made of stainless steel 1.4408 - polished - Shafts made of stainless steel 1.4057 Multiple shaft seals O-rings Shaft bearing in MS socket - Manual operation of butterfly valves by means of hexagonal 17 mm on the blind side Test pressure: 13 bar for leaks |
