Discover the superior quality and performance of the Bauer 189F3306 - BS06-61U/DHE07LA4/MG with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 189F3306 - BS06-61U/DHE07LA4/MG is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 189F3306 - BS06-61U/DHE07LA4/MG :
At Onrion LLC , we offer the 189F3306 - BS06-61U/DHE07LA4/MG at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 189F3306 - BS06-61U/DHE07LA4/MG ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Bauer |
Product | 189F3306 - BS06-61U/DHE07LA4/MG |
Description | Worm gear motor |
Internal code | ONR4868859 |
Custom code | 85015100 |
Technical specification | BS06-61U/DHE07LA4/MG Motor power: 0.25 kW AW speed: 9.4 r/min Torque (max. allowable): 106 Nm Operating factor fB: 1.0 Line-up: H1/V2 Terminal box location: II/ A Corrosion protection: standard Paint: 1K primer Dimension picture: BS06 Additional/special versions: Design H1 tilted 45° according to design V2. Transmission design: Type: BS06 2-stage worm gear Version code 61U with foot thread on the bottom side Pin shaft on transmission side V (d: 25 mm) Total reduction i: 146.8 Additional/special versions: Lubricant type: PGLP 220 Engine version: Type: DHE07LA4 three-phase cage rotor motor Rated speed: 1375 r/min Voltage: 230/400 V Stator circuit: D/Y Frequency: 50 Hz Rated current: 1.32/0.76 A Cos phi power factor: 0.68 Efficiency: IE2 - 69.4% (according to EN 60034-2-1) Warmth class: F IP protection class in accordance with EN 60529: IP 65 IC cooling type in accordance with EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 |
