Discover the superior quality and performance of the Boll Kirch 1.03.2.520.500 DN 250 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1.03.2.520.500 DN 250 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1.03.2.520.500 DN 250 :
At Onrion LLC , we offer the 1.03.2.520.500 DN 250 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 1.03.2.520.500 DN 250 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | 1.03.2.520.500 DN 250 |
| Description | Simplex Filter |
| Internal code | ONR1782287 |
| Weight | 350 |
| Technical specification | Filter type : 1.03.2 Housing size : 520.500 Nominal diameter : DN 250 Flange connection according to : DIN 2501 PN 10 with counter flanges Dimension drawing : Z45539 --- OPERATIONAL DATA --- Medium to be filtered : heavy fuel oil Group of fluid in accordance with PED : 1 Max. Flow rate : 100,00 m³/h Operating pressure : 6,00 bar Allowable operating pressure : 10,00 bar Min. allowable operating temperature : 0,00 °C Max. allowable operating temperature : 80,00 °C --- DESIGN/APPROVAL --- Design according to : PED2014/68/EU AD-2000 Vessel volume : 157,00 litre Hydraulic pressure test by : Boll & Kirch with certificate Material certificates : EN 10204/3.2 --- MATERIALS --- Filter housing : ductile cast iron (EN-GJS-400-15) Seals : Viton GF-S --- FILTER ELEMENTS --- Type of filter element : basket element Material of filter element : steel/aluminium Filter mesh made of : stainless steel (1.4401) Mesh no. : 26 Grade of filtration : 800 μm Filtration area : 7000 cm² --- ACCESSORIES --- Differential pressure indicator : 4.36.1 (optical) Setting of DPI : 0 - 0,5 bar Counter flanges with bolts + gaskets : included DPI : with stopcock Drain with ball valve : ja/yes Vent with ball valve : ja/yes lifting lugs : ja/yes filter with cover safety device : ja/yes --- CORROSION PROTECTION --- External painting : Anstrich aussen : 2K-Ep RAL 8007 Internal conservation : Hydraulic oil ISO VG 32 --- MARKING --- Instruction/name plate : English Filter without CE-marking : Marking on filter : GOEGC11AT011 Marking on packing : GOEGC11AT011 --- DOCUMENTATION --- Language of Operating instruction in : English Operating instruction : 1x pdf Inspection certificates : 1x |
