Discover the superior quality and performance of the Boll Kirch 6.21 Gr 05 DN 50 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 6.21 Gr 05 DN 50 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 6.21 Gr 05 DN 50 :
At Onrion LLC , we offer the 6.21 Gr 05 DN 50 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 6.21 Gr 05 DN 50 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Boll Kirch products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Boll Kirch |
| Product | 6.21 Gr 05 DN 50 |
| Description | automatic filter |
| Internal code | ONR4310923 |
| Custom code | 842199 |
| Technical specification | Filter type: 6.21 size 05 Nominal connection size: DN 50 Connection flanges to: WN165, square flanges Dimension sheet: Z144863 — OPERATING CONDITIONS — fluid to be filtered: fuel fluid group according to PED: 1 Fluid type according to PED: liquid Maximum allowable pressure: 16.00 bar perm. Operating temperature min: 0.00 °C perm. Max. operating temperature: 150.00 °C — BACKWASH — Backwash medium: own medium Flush volume: 0.20 l/h at 5.00 bar Control medium: air 4-7 bar ISO 8573-1:2010 (7/4/4) Operating voltage: 3 ph 440 volts Frequency: 60 Hz Control voltage: 220 volts control: Type 2300 : ID 4302300 Control language: English — CONSTRUCTION/ACCEPTANCE — Design and design: PED2014/68/EU AD-2000 : Art. 4, para 3 Volume of container: 3.50 liters Curb weight: 40 kg Pressure test according to: Boll & Kirch with certificate Material certificates: EN 10204/3.1 — MATERIALS — filter housing manufactured from: EN-GJS-400-15 Seal made of: Viton GF-S — FILTER ELEMENTS — Item Type: Multi Segment Element no. of filter elements: 1 No. of filter elements per chamber: 1 No. of filter chambers: 1 Woven fabrics: 1.4401 Fabric number: 294/31 abs. filter fineness: 34 μm Screen area in operation: 2000 cm² Screen area total: 2000 cm² — ACCESSORIES — installed differential pressure indicator: 4.36.2 (optic+electric) Differential pressure gauge sealant: Viton GF-S Backwash differential pressure setting: 0.60 bar/ alarm 0.80 bar counterflan. Screws and seals: included: drilled DN40 — Accessories/differential pressure measurement — DDA: with stopcocks yes — CORROSION PROTECTION — Base coat outside: 2K Ep RAL 5005 Internal preservation: Shell Tellus S2 M 32 — MARKING — Operation/factory plate: German/English CE marking according to: - Machinery Directive 2006/42/EC: CE — DOCUMENTATION — User manual language in: German/English Owner's manual: 1x pdf Acceptance certificates/certificate: 1x pdf Declaration of conformity: included |
