Discover the superior quality and performance of the Stahl P/N: 201422, Type: 8146/5-V37-304-50-0010 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N: 201422, Type: 8146/5-V37-304-50-0010 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N: 201422, Type: 8146/5-V37-304-50-0010 :
At Onrion LLC , we offer the P/N: 201422, Type: 8146/5-V37-304-50-0010 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the P/N: 201422, Type: 8146/5-V37-304-50-0010 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Stahl |
Product | P/N: 201422, Type: 8146/5-V37-304-50-0010 |
Description | safety switch |
Internal code | ONR4610207 |
Custom code | 85371098 |
Technical specification | Safety switch 25 A | Explosion proof | Type: 8146/5-V37-304-50-0010 | Replacement by type: 8537/2-303-7000 | 8537/2-703-7000 | Rated operating voltage AC: 690 V | Rated operating current: 25 A | Housing material: polyester resin glass reinforced | Detailed number of poles: 3-pole | Auxiliary contact normally closed: none | Auxiliary contact normally open: 1 NO/lag | Additional terminal: Standard (none) | Area of application (zones): 1, 2, 21, 22 | Gas Explosion Protection: II 2 G Ex db eb IIC T6 Gb | Dust explosion protection: II 2 D Ex tb IIIC T80 °C Db | Ambient temperature min.: -40 °C | Ambient temperature max.: +40 °C | Special conditions for extended ambient temperature, | see Operating instructions: | Extended ambient temp. min.: -40 °C | Extended ambient temp. max.: +55 °C | Protection class (IP): IP66 | Cable entry: 2 x M32 Ø 9... 21 mm | 1 x M20 Ø 4... 13 mm | Connection cross-section: 4... 6 mm2 | HIKO connection cross-section: 1.5... 4 mm2 stranded | 1.5... 6 mm2 solid |
