Discover the superior quality and performance of the Hengesbach A-CONDUTEC_K_PZM_00H4 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The A-CONDUTEC_K_PZM_00H4 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of A-CONDUTEC_K_PZM_00H4 :
At Onrion LLC , we offer the A-CONDUTEC_K_PZM_00H4 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the A-CONDUTEC_K_PZM_00H4 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Hengesbach products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Hengesbach |
| Product | A-CONDUTEC_K_PZM_00H4 |
| Description | Transmitter |
| Internal code | ONR3365026 |
| Weight | 10 |
| Custom code | 90278930 |
| Technical specification | CONDUTEC_K_PZM_00H4 Conductive Conductivity Meter Compact design (transmitter and conductivity measuring cell fixed connected). Process connection: PZM modular system with pressure screw, material Wkst. 1.4404/1.4435. /*** Delivery incl. - O-ring seal 28x2.5, EPDM material, FDA compliant, temperature Operating range -40°C... +150°C Order details Electrical connection: M12 plug 4-pin Connections: 1. Conductivity and supply (+) pin 1; pin 3 (-) 2nd temperature (+) pin 2; pin 4 (-) --- 1. Transmitter: Polyamide housing, dimensions 100x100x60mm³, with integrated digital display. Measurement ranges freely programmable from 0.. 20 μS/cm to max. 0.. 500 mS/cm (see relevant technical data of the LF measuring cell) 1st output 4-20 mA, 2-wire for conductivity, galvanically isolated 2nd output 4-20 mA in 2-wire for temperature, programmable in the range T=- 40.. +160°C 2 contactless alarm outputs Supply voltage 14... 30 VDC 2. 4-electrode conductivity measuring cell Can be used for conductivities ranging from 0... 1 mS/cm to 0... 500 mS/cm. Accuracy approx. 0.02 mS/cm. Cell constant C=0.4 (C=0.5 for process connection G1 and G3) Working temperature TA = -10... +120°C. Can be steam sterilised for 1 h up to TR = 140°C. Pressure resistance 16 max. bar Temperature measurement with integrated Pt1000 in accordance with DIN IEC 751. Parts in contact with media made of PEEK, PVDF, graphite and stainless steel (wkst. 1.4404). According to the A-CONDUTEC data sheet... in the currently valid version. |
