Discover the superior quality and performance of the Bauer BG30-37/D09XA4-TF/C3 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BG30-37/D09XA4-TF/C3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BG30-37/D09XA4-TF/C3 :
At Onrion LLC , we offer the BG30-37/D09XA4-TF/C3 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BG30-37/D09XA4-TF/C3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bauer |
| Product | BG30-37/D09XA4-TF/C3 |
| Internal code | ONR4765596 |
| Custom code | 85015220 |
| Technical specification | Material number 30519629 BCAS item number 188Y6740 Article number: 188Y6740 Spur gear motor BG30-37/D09XA4-TF/C3 Motor power: 2.2 kW Speed of the AW: 132 r/min Line-up: B5 Terminal box location: IV/ A Corrosion protection: Coro 3 Painting: RAL 7031 Dimensional image: BG30-BG30Z Catalogue: DG 07 Net weight per piece: approx. 42 kg Additional/special versions: Total coating thickness 130 µm Suitable for operation on a static converter in the frequency range: 10 - 50 - 60 Hz Voltage: 102 - 400 - 400 V D S 3-40% output: 0.45 - 2.8 - 3.4 kW Synchronous. Speed: 28.0 - 140 - 169 r/min S 3-40% load torque: 154 - 205 - 205 Nm Load current approx.: 7.4 A Operating factor: 1.3 Transmission design: Type: BG30 2-stage helical gearbox Version code number 37 with standard flange on front side (d: 200 mm) Pivot shaft on transmission side V for flange version (d: 30 mm) Total reduction i: 10.65 Motor design: Type: Three-phase squirrel cage motor D09XA4-TF Rated speed: 1400 r/min Voltage: 400 V Stator circuit: D frequency: 50 Hz Rated current: 5.1 A Power factor cos phi: 0.80 Warmth class: F IP protection class according to EN 60529: IP 66 IC cooling type according to EN 60034-6: IC 411 Terminal box: TB222 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermistors for shut-off according to additional connection diagram ZK010.1040-14. Please note: motor IP66: connection chamber separated from the engine interior by sealing compound; protected against short-term flooding, with increased corrosion protection. The motor is connected via CAGE-CLAMP (cage tension spring technology)! CAGE CLAMP is a registered trademark of WAGO |
