Discover the superior quality and performance of the Bauer BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 :
At Onrion LLC , we offer the BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bauer |
| Product | BG60-11/DPE11LB4C-TF-S/ES040A9 / 189F3149 / 30709485 |
| Description | Spur gear motor |
| Internal code | ONR4726930 |
| Custom code | 85015220 |
| Technical specification | Material number 30709485 BCAS item number 189F3149 Description BG60-11/DPE11LB4C-TF-S/ES040A9 Spur gear motor with single-disc spring brake BG60-11/DPE11LB4C-TF-S/ES040A9 Motor power: 5.5 kW Speed of the AW: 109 r/min Line-up: B3 Terminal box location: I/A Corrosion protection: standard Painting: RAL 7031 Dimensional image: BG60-BG60Z Catalogue: B 2010 Net weight per piece: approx. 124 kg Suitable for operation on a static converter in the frequency range: 5 - 50 - 87 - 100 Hz Voltage: 34 - 230 - 400 - 400 V D Power: 0.335 - 3.25 - 5.8 - 6.6 kW Synchronous Speed: 11.0 - 111 - 193 - 220 r/min const. Load moment: 290 Nm Load current approx.: 14.9 A Operating factor: 3.5 Transmission design: Type: BG60 2-stage helical gearbox Version code number 11 Base with holes on the bottom of the page Pivot shaft on transmission side V (d: 50 mm) Total reduction i: 13.47 Oil type/quantity (l): CLP 220/ 5.5 Motor design: Type: Three-phase squirrel cage motor DPE11LB4C-TF-S Rated speed: 1465 r/min Voltage: 230 V Stator circuit: D frequency: 50 Hz Rated current: 19.1 A Power factor cos phi: 0.80 Efficiency: IE3 - 90% (according to EN 60034-2-1) Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG3 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermistors for shut-off according to additional connection diagram ZK010.1040-14. Brake design: holding brake under the fan cover Type: Single disc spring brake ES 040 A 9 Setting value: 40.0 Nm IP protection class according to EN 60 529: IP 65 coil voltage: 180 V Coil current: 0.33 A Additional measurement image: N-BR Cable design, solenoid coil connectors connected to rectifiers in the motor terminal box. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.23 A DC output: 180 V Please note: motor The motor is connected via CAGE-CLAMP (cage tension spring technology)! CAGE CLAMP is a registered trademark of WAGO Operation at increased input speed results in increased operating noise and a increased heating of the drive. Operating at an increased input speed reduces the life of the shaft seals, What needs to be considered when allocating service intervals. Product information in accordance with EU Regulation (EU) 2019/1781 Annex I Sector 2: https://www.bauergears.com/euprodinfo Please check whether the allocation of voltage and frequency for motor and inverter is the same. brake When operating at different frequencies (frequency jump, inverter operation), the brake must be switched from a separate Network (possibly control network) (risk of destruction due to voltage surges). |
