Discover the superior quality and performance of the Bauer BK20-24VW/DPEU09XB4/IM2-SP with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BK20-24VW/DPEU09XB4/IM2-SP is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BK20-24VW/DPEU09XB4/IM2-SP :
At Onrion LLC , we offer the BK20-24VW/DPEU09XB4/IM2-SP at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BK20-24VW/DPEU09XB4/IM2-SP ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bauer |
| Product | BK20-24VW/DPEU09XB4/IM2-SP |
| Description | bevel gear motor |
| Internal code | ONR4940483 |
| Custom code | 85015220 |
| Technical specification | Article number: 189B8873 Motor power: 1.1 kW AW speed: 51 r/min Torque: 185 Nm Operating factor fB: 1.8 Lineup: H2/H3 Terminal box location: III/A Corrosion protection: IM2 Paint: Wimes Dimension diagram: BK20-S1/30 Catalogue: B 2010 Additional/special versions: Design H2 tilted by 30° according to design H3. Submersible (IP68) up to max. 5m Special cable fittings in accordance with ZN.BAU2583721. M25X1,5-MS HSK-MZ-EX New ID 30366338 + M32/M25 ATEX reduction Material number: 30370050 Special cable motor according to ZN.MWN 0558 P.1. Ölflex Crane (Neoflex) 7x2.5 mm² 10 m directly connected and sealed ID No. 30366041 Gearbox design: Type: BK20 2-stage bevel gearbox Design code 24VW with small flange on front side (d: 200 mm) Hollow shaft with spring groove (d: 30 mm) Total reduction i: 28.66 Additional/special versions: With special working shaft K30 V4A, d: 30 mm With double shaft sealing on the working shaft. Wheel 3 reinforced support Sealing cap on transmission side H Lubricant grade: PGLP 460 Engine design: Type: DPEU09XB4 three-phase cage rotor motor Design speed: 1440 r/min Voltage: 400 V Stator circuit: Y Frequency: 50 Hz Rated current: 2.4 A cos phi power factor: 0.77 Efficiency: IE3 - 85.7% (according to EN 60034-2-1) Warmth class: F IP protection class n. EN and f: IP 68 IC cooling type according to EN 60034-6: IC 410 Terminal box: TB222 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: Terminal box design with terminal board |
