Discover the superior quality and performance of the Labom BR4201-A57.59-N4200-W4105-W5417 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The BR4201-A57.59-N4200-W4105-W5417 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of BR4201-A57.59-N4200-W4105-W5417 :
At Onrion LLC , we offer the BR4201-A57.59-N4200-W4105-W5417 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the BR4201-A57.59-N4200-W4105-W5417 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Labom products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Labom |
| Product | BR4201-A57.59-N4200-W4105-W5417 |
| Internal code | ONR4587424 |
| Custom code | 90262040 |
| Technical specification | DL2100-A4007-L23-T99-U3 BR4 BOURDON TUBE PRESSURE GAUGE with diaphragm seal connection and switch contact acc. to data sheet D3-027 2 case: NS 100 0 case design: IP 65, process connection bottom 1 design: with ex-protection A accuracy class: see data sheet 57 nominal range: 0...6 bar 59 double scale: 0...6 bari inside black, 0...0.6 MPa outside black, same font size N4 inductive contact with standard initiator (N) 200 switch function: 1 x max. open contact Ex design for inductive contact device: P+F SJ2-N / SJ3.5-N PTB 99 ATEX 2219X II 2G Ex ia IIC T4/T5/T6 Gb Ex design (ATEX) for mechanical instruments: II 2G Ex h IIC T1...T6 Gb X, II 2D Ex h IIIC Txx°C Db X Please pay attention to the application conditions, which can be taken from the data sheet and the ex-safety instructions XA_005 and XA_013. Temperature limits might be changed with implementation of EN ISO 80079-36:2016 and EN ISO 80079-37:2016 valid from 01.11.2019. electrical connection: connection plug with cable gland M20 x 1.5 and removable test cover, mat. Macrolon W4105 ADDITIONAL DESIGN: wetted parts free of silicon W5417 CUSTOMERS SPECIFICATION: Contact Settings Functionality while pointer moves clockwise Increasing pressure breaks contact Contact set to 2.0 bar Contact alignment - polarity 3- and 4+ (max) Stop pin on right hand side of contact pointer at 3 bar DL DIAPHRAGM SEAL for food / pharmaceutical / biotechnology 2 design with coupling nut see data sheet D5-025 100 process connection: DIN 11851, DN 25 / PN 40 A400 connection of meas. instrument directly welded 7 material wetted parts: stainless steel mat.-no. 1.4435 (316L) L23 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered T99 temperature, media: see below -20...+150°C U3 temperature, ambient: 0..+50 °C Spare part for fab.-no. 2001527/30/006 |
