Discover the superior quality and performance of the Baelz D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) :
At Onrion LLC , we offer the D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Baelz products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Baelz |
| Product | D-DAMPF-JET (Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011) |
| Description | Steam ejector with mounted actuator |
| Internal code | ONR3836057 |
| Weight | 85 |
| Custom code | 84818099 |
| Technical specification | Best.-Nr. D-DAMPF-JET consists of Best.-Nr. 591-X and Best.-Nr. 373-E45-40-15-5011 Steam cooling and reducing Jetomat Desuperheater 591 body material: GJS-400-18-LT 5 5.3103 max. 240°C/12,3 bar -50°C/16 bar DN 100, PN 16 nozzle 56 mm, KT 30889 stroke 40 mm spindle-Ø 16 mm conditions in: am pressure: p01 min. 5 bar g / max. 9 bar g steam temperature: T01 min. 159°C / max. 180°C steam flow: m01 min. .. kg/h / max. 4680 kg/h cooling water: p02 min. 13 bar g / max. ... bar g cooling water temperature: T02 min. ..°C / max. 27°C cooling water flow: min. .. l/h / max. 200 l/h noise level: max. 101 dB(A) conditions out: steam pressure: p04 min. 0,43 bar g / max. … bar g steam temperature: T04 min. 110°C / max. …°C steam flow: m04 min. .. kg/h / max. 4800 kg/h delta p max. 16 bar (actuator) P04 and T04 depend on a pressure drop of nozzles in the cylinder. Cooling water quality: pH-value 8,5...9,5 Hardness < = 0,9 ppm (0,009 mmol/l) Electric conductivity <= 1 μs/cm Silic acid (SiO2) <= 0,1 mg/l Best.-Nr. 373-E45-40-15-5011 Digitaler Motorhubantrieb stetig 4000 N;15 mm/min.; 0/2-10V o. 0/4-20 mA; Ø 16 mm 373-E45-40-15-S21-L-2EZ-Fg5k-7020A-230 Selbstadaptierung 1 Eingangssignal: 0/2…10 V oder 0/4…20 mA Auslieferzustand: 0…10 V 2 Ausgangssignale: Ausgang 1: 0…10 V und Ausgang 2: 0…20 mA oder Ausgang 1: 2…10 V und Ausgang 2: 4…20 mA Auslieferzustand: 0…10 V und 0…20 mA 1 digitaler Eingang frei einstellbar über Software 2 Relais frei einstellbar über DIP-Schalter Hilfsumschaltkontakte 12…250 VAC Schnittstelle: RS 485 Modbus RTU 2 zusätzl. Endschalter, 1 Ferngeber 5 kOhm einschl. Antriebsständer und Kupplung (S21L) für Armaturen mit Spindel-Ø16 mm IP 65; Hub max. 40 mm 230 V, 50/60 Hz |
