Discover the superior quality and performance of the C.E. srl CFIB - 4 - RD – P3 - ET- S with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CFIB - 4 - RD – P3 - ET- S is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CFIB - 4 - RD – P3 - ET- S :
At Onrion LLC , we offer the CFIB - 4 - RD – P3 - ET- S at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CFIB - 4 - RD – P3 - ET- S ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply C.E. srl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | C.E. srl |
Product | CFIB - 4 - RD – P3 - ET- S |
Internal code | ONR4726804 |
Custom code | 90330000 |
Technical specification | n.10 GLOBTOP case mod. CFIB in 316L stainless steel, with open/closed position indicator for rotary valves (maximum resistance to chemical and atmospheric agents) ATEX certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC IP66/67 T85/T100/T135°C (Tamb. from -25°C to +60/+80/+100°C) - Cable entry: No. 3 3/4 “npt-f holes - Terminal block: 12 terminals plus earth connection - Degree of protection: IP66/67/67M - Treatment: electropolishing - Position indicator: three-dimensional red-green dome - Shaft: namur coupling — 316 stainless steel material 4 magnetic proximity sensors (2AP +2CH) will be mounted in each JETREED enclosure with the following characteristics: - passive magnetic limit switch Mod. P3 (without power supply) - Reed type contact: SPDT in Rhodium (hermetic with inert gas) - DC-AC switching current: 1Amp maximum with resistive load - DC-AC switching voltage: 240V maximum resistive load - DC/AC WATTS switching power: maximum 25 VA-W resistive load (Sensor supply barrier suitable for the following values: - Ui 30V, Ii 120mA, Pi 1000mW) - sensitive distance: 4 mm. - reset distance: 0.6 mm. - switching time: 3.6 milliseconds - release time: 4.2 milliseconds - operating temperature: from - 25°C to + 125°C - material casing: PPS with degree of flammability “V0" - 3 connection conductors |
