Discover the superior quality and performance of the TEKNIC CPM-MCPV-2311S-RLN with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CPM-MCPV-2311S-RLN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CPM-MCPV-2311S-RLN :
At Onrion LLC , we offer the CPM-MCPV-2311S-RLN at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CPM-MCPV-2311S-RLN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply TEKNIC products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | TEKNIC |
Product | CPM-MCPV-2311S-RLN |
Description | Integrated Servo System |
Internal code | ONR4705800 |
Technical specification | Motor Frame SizeNEMA 23 - 2.33 in (59.18 mm) sq. Length3.34 in (84.84 mm) Input (bus) Voltage Range24-75 VDC (90 VDC max) Peak Torque (@75 VDC)290 oz-in (2.0 N-m) Cont. (RMS) Torque (@75 VDC)58 oz-in (0.4 N-m) Max Speed (@75 VDC)4000 RPM Achievable Resolution0.450 degrees (0.057 deg. w/ Enhanced option) Repeatability0.03 degrees Shaft Diameter0.375 in (9.53 mm) Rotor Inertia0.4 oz-in² (0.1 kg-cm²) Logic Input Voltage Range4.0 to 28 VDC Maximum Radial Load25 lbf (111.2 N) Maximum Thrust Load5.0 lbf (22.2 N) Ambient Temperature1-40° to +70° C Ambient Humidity0-95%; non-condensing Environmental RatingDust & water splash resistant Regulatory CertificationsUL recognized; cUL recognized; CE; RoHS Safety2Supports STO (IEC 60204-1) Safety Requirements |
