Discover the superior quality and performance of the Calectro CPS-D-A-9500 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CPS-D-A-9500 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CPS-D-A-9500 :
At Onrion LLC , we offer the CPS-D-A-9500 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CPS-D-A-9500 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Calectro products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Calectro |
| Product | CPS-D-A-9500 |
| Internal code | ONR4938627 |
| Technical specification | Calectro differential pressure transmitter -100... +9500 Pa with display The CPS-D-A-9500 pressure sensor has a built-in differential pressure element, which for a high Accuracy and linearity are temperature-compensated. The differential pressure element and the output signal have a high resolution, which means that the pressure value is in steps of max. 1 Pa over the entire Measurement range (-100 to + 9500Pa) is presented. The desired function and measurement range are determined by set an illuminated display. The pressure measurement range determines at which measurement value the Start the output signal and when the maximum output signal should be given. output signal (0- 10V or 4-20 mA), K factor for volume measurement and the desired signal attenuation are also set via the display. CPS-D-A-9500 is factory-fitted for differential pressure measurement in the range 0-500 Pa, 0-10V output signal and medium signal attenuation (10 sec.) delivered. The measurement range can be random from -100 Pa to +9500 Pa, in steps of 50 Pa. CPS-D-A-9500 can be set via the setting Measure the volume/flow rate of the K-factor using, for example, fans or measurement ports. Die The conversion formula from differential pressure to volume is: q = k x?? p. The K factor can be used with two Decimal places can be set. Various units can also be set: m³/h, m³//s and l/s. The unit setting is just a display label and therefore does not perform a mathematical calculation off the measured value. The measurement range can be indiscriminately from 0 to 32000, in steps of 100 to 3500 and in Steps of 500 from 3500 can be set. TECHNICAL DATA Supply voltage: 24V AC/DC ± 10% power consumption: 43 mA Output signal: 0-10V (>5 k? imp.) /4-20 mA Average attenuation: 3.10 or 20 sec Pressure ranges: Adjustable from -100 to +9500 Pa, in steps of 50 Pa Volume ranges: adjustable from 0 to +32000, in steps of 100 to 3500 and in steps of 500 to 3500 - Selectable standard symbols on the display: m³/h, m³//sec or l/sec - K factor: 0-9999.99 Accuracy: Normally ± 1% of measured pressure (@ <-100 Pa/>+100 Pa) Display: graphical LCD with backlight Ambient temperature: -20 to +50°C Cable inputs: 1xM16, 5-10 mm cable dimensions (WxHxD): 78 x90x40 m Weight: 92g 2 m hose and 2 nipples Protection class: IP54 |
