Discover the superior quality and performance of the Labom CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 :
At Onrion LLC , we offer the CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Labom products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Labom |
| Product | CS2110-A1090-H11-N71-T31-K1085-W4020-W2002 DF3710-HY-F4-A4007-L22 |
| Description | pressure transmitter |
| Internal code | ONR4804468 |
| Custom code | 90262020 |
| Technical specification | CS2110- PRESSURE TRANSMITTER/PRESSURE SWITCH PASCAL CS for diaphragm seal operation, hygienic, see data sheet D4-017-42 A1- pressure sensor: piezoresistive for gauge pressure 090- measuring range -1...5 bar, overload limit 20 bar measuring accuracy: linearity, hysteresis, repeatability <= 0.2 % of span H11 - output signal: 4...20 mA, 2-wire technology N71 - switching output: 2 floating contacts with common power supply (PNP), switching capacity 30 VDC, 200 mA T31 - electrical connection: circular connector M12x1 (8 pins) K1085- design: standard W4020 - ADDITIONAL DESIGN: marking (adhesive label), see below W2002 CALIBRATION PROTOCOL: with 5 measuring points DF- INLINE DIAPHRAGM SEAL for food / pharmaceuticals / biotechnology see data sheet D5-064 37 - process connection: for ISO 1127-pipes Tri-clamp connection on both sides 10 -nominal width: pipe DN/OD 13.5, pipe inside-ø 10.3 mm Tri-Clamp connection DN 1/2", PN 25, outside-ø 25 mm HY- hygienic design per EHEDG Doc.8 and ASME BPE SF3: surface roughness (wetted parts) - turned parts Ra <= 0.76 µm - diaphragm Ra <= 0.38 µm - weld seam Ra <= 0.76 µm F4 insertion length L: 96 mm A400 connection of meas. instrument directly welded 7 material wetted parts: diaphragm st. steel mat.-no. 1.4435 (316L), basic body st. steel mat.-no. 1.4404 (316L) L22 system filling: Synthetic oil, free of silicon FD1 acc. to FDA 21 CFR 178.3570 / H1-registered operating temperature range -10...+140 °C |
