Discover the superior quality and performance of the Carlo Gavazzi CTD2X1205AXXX with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CTD2X1205AXXX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CTD2X1205AXXX :
At Onrion LLC , we offer the CTD2X1205AXXX at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CTD2X1205AXXX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | CTD2X1205AXXX |
| Description | AC Current Transformer |
| Internal code | ONR241847 |
| Weight | 1 |
| Technical specification | AC Current Transformer (max 30x10mmbus-bar) Type CTD-2X • Bus-bar type current transformer • 0.5 class, currents from 40 to 600 A • Integrated DIN-rail mounting holder • Removable panel fixing clips • 2 Bus-bar isolated fixing screws • Double screw terminals (up to 8-wire connections) • Sealable terminal block covers Product Description Ordering Key CTD-2X 200 5A XXX Cable/Bus-bar type current transformerwith DIN-rail/bus- bar and panel mounting facili- Type Selection ty. Rated primary currents from 40 A to 600 A. Model Primary current Secondary current Option Optional fixing kit: CTD-kit Primary current From 40 to 600A (Refer to Range Table) Input Specifications Secondary current 1A 5A Option XXX:none XTX:tropicalization Operating frequency45 to 65 Hz Max. system voltage0.72 kV Rated insulation level3 kV/1 min. @ 50 Hz Insulation class E (max 75°C) Short-time current rating Ith Typical 100 In /1 s Idyn 2.5 Ith The short-time thermal current Ith is anyway limited by the cable/ bus-bar size Extended current rating 120% Security factor (FS)≤ 5 (Class: 0.5, 1 and 3) General Specifications Standards According to EN60044-1 HousingABS, self-extinguishing: UL 94 V-0 MountingDIN-rail bus-bar and panelmounting Standard accessoriesTwo terminal blockscrews. Two cable/bus-bar fixingscrews. Two sealable terminal block covers. Two panelmounting fixingclips. Two plastic caps for cable/bus-bar fixingscrews. Optional accessoriesExtended fixing kit: CTD-kit Two panel mounting fixing clips. Six cable/bus-bar fixing screws. Six plastic caps for cable/bus-bar fixing screws. Special features 1 A secondary current, Tropicalization Working temperature-25°Cto +60°C (-13°F to 140°F) (R.H.< 90% non condensing @ 40°C) Storage temperature -30°Cto +70°C (-22°F to 158°F) (R.H.< 90% non condensing @ 40°C) Approvals CE, cUrus and CSA Connection Screw type Cablecrosssection areaFrom1.5 to 6 mm2 Min/Max screws tightening torque relevant to terminal blockscrews: From1 to 2 Nm Max screws tightening torque relevant to the cable/bus-bar fixingscrews: 0,3 Nm Protection degreeIP00 IP20(withsealable terminal block covers + wire terminals) Cablediameter Max. 24 mm Bus-bar size HorizontalMax. 32x5 30x10 25x20 mm Vertical Max. 25x12mm Weight From350 to 500 g Output Specifications Rated secondary current5 A or 1 A |
