Discover the superior quality and performance of the Labom CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 :
At Onrion LLC , we offer the CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Labom products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Labom |
| Product | CV3100-B1056-F10-H1110-M2-N10-T20-K1010 W4020 W1020 |
| Description | Pressure transmitter |
| Internal code | ONR4799168 |
| Custom code | 90262020 |
| Technical specification | PRESSURE TRANSMITTER PASCAL CV with threaded connection acc. to data sheet D4-017-1 pressure sensor: piezoresistive for absolute pressure nominal range: 0...4 bar abs., overload limit 10 bar measuring range setting: turndown 5:1 accuracy: <= 0.15% of measuring span (linearity, hysteresis and repeatability) measuring range: 0...4.000 bar abs. output signal: 4...20 mA, rising characteristic (standard) setting damping set to (sec.): 3,0 setting alarm state: < 3.6 mA (standard) display module: multifunctional display with 5-position digital display and bar graph, pluggable switching module: without case: hygienic housing design with screw cap material: stainless steel degree of protection: IP 66 electrical connection: cable gland M 16 x 1.5, polyamide black process connection: internal diaphragm, G 1/2 B per DIN EN 837-1 material: - diaphragm, stainless steel mat. no. 1.4404/1.4435 (316L) - socket, stainless steel mat. no. 1.4404/1.4435 (316L) ADDITIONAL DESIGN: marking (adhesive label), see belowW4020 Components marked acc. to material inspection certificate per EN 10204-3.1, wetted parts |
