Discover the superior quality and performance of the Labom CV3110 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CV3110 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CV3110 :
At Onrion LLC , we offer the CV3110 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CV3110 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Labom products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Labom |
| Product | CV3110 |
| Description | PRESSURE TRANSMITTER PASCAL CV, |
| Internal code | ONR4489599 |
| Custom code | 90262020 |
| Technical specification | CV3110-A1059-F80-H2100-M2-N10-T20-K1085-W2002 DL3130-A4007-L32-T63-W4001-W1020-W1102.1.99 for diaphragm seal operation, hygienic acc. to data sheet D4-017/22 A1 pressure sensor: piezoresistive for gauge pressure 059 nominal range: 0...16 bar, overload limit 60 bar measuring range setting: turndown 5:1 accuracy: <= 0.15% of measuring span (linearity, hysteresis and repeatability) F80 measuring range: setting see below lower range value: 0 upper range value: + 10,000 unit: bar H21 output signal: 4...20 mA with HART function module 0 setting damping: 0.0 sec. (standard) 0 setting alarm state: < 3.6 mA (standard) display module: multifunctional display with 5-position digital display and bar graph, pluggable M2 N10 switching module: without case: hygienic housing design with screw cap material: stainless steel degree of protection: IP 66 T20 electrical connection: cable gland M 16 x 1.5, polyamide blac K1085 design standard W2002 CALIBRATION PROTOCOL: with 5 measuring points DL DIAPHRAGM SEAL for food / pharmaceutical / biotechnology design with clamp connection see data sheet D5-026 3 process connection: per DIN 32676 model C (Tri-Clamp) for pipes per ASME BPE, DN 1" / PN 25 130 A400 connection of meas. instrument directly welded 7 material wetted parts: stainless steel mat.-no. 1.4435 (316L) L32 system filling: neobee M20 FNM20 T63 temperature, media: -10..+140 °C W4001 ADDITIONAL DESIGN: free of oil and grease for oxygen applications Components marked acc. to material inspection certificate per EN 10204-3.1, wetted parts W1020 TEST REPORT per DIN EN 10204 2.2 as per customers specification, see below W1102 .1 -confirmation of used materials .99 -confirm BSE-/TSE free |
