Discover the superior quality and performance of the Carlo Gavazzi DAC01CM24 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DAC01CM24 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DAC01CM24 :
At Onrion LLC , we offer the DAC01CM24 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DAC01CM24 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | DAC01CM24 |
| Description | FUNCTION Star-Delta OUTPUT SIGNAL 1 |
| Internal code | ONR246971 |
| Weight | 1 |
| Technical specification | Timers StarDelta Types DAC01, PAC01 DAC01 PAC01 • Time range (Star): 0.1 to 600 s • Time range (Star to Delta): 50 to 130 ms • Knob selection of star time range • Knob adjustable time setting • Automatic start • Repeatability: ≤ 0.2% • Output: 8 A SPDT relay with neutral centre position • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 22.5 mm Euronorm housing or 36 mm Plug-in module housing • LED indication for relay status and power supply ON Product Description Ordering key DAC 01 C M24 Star-delta controlrelay with two adjustable time ranges: Star function(0.1 to 600 s) andstartodeltafunction (50 to 130 ms). For mount- ing on DIN-rail (DAC 01) on Plug-in (PAC01). Housing Function Type Item number Output Power Supply Type Selection MountingOutputHousing Supply: 24 to 240 VAC/DCSupply: 380 to 415 VAC For DIN-rail1 x SPDTD - 22.5 mmDAC 01 C M24 DAC 01 C M40 Plug-inP - Housing PAC 01 C M24PAC 01 C M40 TimeSpecificationsOutput Specifications Time ranges (star) Knob selectable0.1 to 1 s 1to 10 s 6to 60 s 60to 600s Star to delta delay50 to 130 ms Neutral centre position between star and delta position Setting accuracy ≤ 5% Repeatability ≤ 0.2% Time variation Within rated power supply ≤ 0.05% Within ambient temperature ≤ 0.2% Reset Time and relayPower supply interruption ≥ 200 ms OutputSPDT relay with neutral centre position Rated insulation voltage250 VAC (RMS) Contact Ratings (AgSnO2) µ Resistive loadsAC 1 8 A @250 VAC DC 12 5 A @24 VDC Small inductive loads AC 15 2.5 A @250 VAC DC 13 2.5 A @24 VDC Mechanical life≥ 30 x 106 operations Electrical life ≥ 105 operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency< 7200 operations/h Dielectric strength Dielectric voltage2 kVAC (RMS) Rated impulse withstand voltage4 kV (1.2/50µs) Specifications are subject to change without notice (20.06.07)1 |
