Discover the superior quality and performance of the Carlo Gavazzi DAC51CM24 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DAC51CM24 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DAC51CM24 :
At Onrion LLC , we offer the DAC51CM24 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DAC51CM24 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | DAC51CM24 |
| Description | FUNCTION Star-Delta OUTPUT SIGNAL 1 |
| Internal code | ONR246980 |
| Weight | 1 |
| Technical specification | Timers StarDelta Timer Type DAC51 • Time range (Star): 0.1 to 600 s • Time range (Star to Delta): 50 to 130 ms • Knob selection of star time range • Knob adjustable time setting • Automatic start • Repeatability: ≤ 0.2% • Output: 5 A SPDT relay with neutral centre position • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 17.5 mm Din-rail housing (DIN 43880) • LED indication for relay status and power supply ON Product Description Ordering key DAC 51 C M24 Star-delta controlrelay with two adjustable time ranges: Star function(0.1 to 600 s) andstartodeltafunction (50 to 130 ms). Housing 17.5 mm wide suit- able for DIN-rail mounting. Fits in M36 cover. Housing Function Type Item number Output Power Supply Type Selection Mounting OutputHousing Supply: 24 to 240 VAC/DC For DIN-rail SPDT relayMini-D DAC 51 C M24 with neutral centre position TimeSpecificationsOutput Specifications Time ranges (star) Knob selectable0.1 to 1 s 1to 10 s 6to 60 s 60to 600s Star to delta delay50 to 130 ms Neutral centre position between star and delta position Setting accuracy ≤ 5% Repeatability ≤ 0.2% Time variation Within rated power supply ≤ 0.05% Within ambient temperature ≤ 0.2% Reset Time and relayPower supply interruption ≥ 200 ms OutputSPDT relay with neutral centre position Rated insulation voltage250 VAC (RMS) Contact Ratings (AgSnO2) µ Resistive loadsAC 1 5 A @250 VAC DC 12 5 A @24 VDC Small inductive loads AC 15 2.5 A @250 VAC DC 13 2.5 A @24 VDC Mechanical life≥ 30 x 106 operations Electrical life ≥ 105 operations (at 5 A, 250 V, cos ϕ = 1) Operating frequency< 7200 operations/h Dielectric strength Dielectric voltage2 kVAC (RMS) Rated impulse withstand voltage4 kV (1.2/50µs) Supply Specifications Power supplyOvervoltage cat. III Rated operational voltage(IEC 60664, IEC 60038) through terminals A1 and A2 M24: 24 to 240 VAC/DC +10% -15%, 45 to 65 Hz Voltage interruption≤ 10 ms Rated operational power AC Supply5 VA DC Supply1.5 W Specifications are subject to change without notice (20.06.07)1 |
