Discover the superior quality and performance of the Carlo Gavazzi DBA52CM24 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DBA52CM24 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DBA52CM24 :
At Onrion LLC , we offer the DBA52CM24 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DBA52CM24 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | DBA52CM24 |
| Description | FUNCTION Delay on release OUTPUT SIGNAL 1 |
| Internal code | ONR247408 |
| Weight | 1 |
| Technical specification | Timers Delay onRelease Type DBA52 • Time range 0.1 s to 100 h • Knob selection of time range • Knob-adjustable time setting • Repeatability: ≤ 0.2% • Output: 5 A SPDT relay • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 17.5 mm DIN-rail housing • Combined AC and DC power supply • LED indication for relay status and power supply ON Product DescriptionOrdering Key DBA 52 C M24 Multi-voltage delay on release timer with 7 knob selectable time ranges with- in 0.1 s and 100 h. Type Selection For mounting on DIN-rail. Housing Function Type Item number Output Power supply MountingOutput HousingSupply: 24 VDC and 24 to 240 VAC DIN-railSPDT D-Housing DBA 52 C M24 TimeSpecificationsOutput Specifications Time ranges Knob Selectable0.1to 1 s 1 to 10 s 6 to 60 s 60 to 600 s 0.1to 1 h 1 to 10 h 10 to 100 h Setting accuracy≤ 5% Repeatability≤ 0.2% Time variation Within rated power supply ≤ 0.05%/V Within ambient temperature≤ 0.2%/ºC Reset Manual reset of time and/or relayClose the trigger contact between pins A1 and Y1 Pulse duration≥ 100 ms Power supply interruption≥ 200 ms Output SPDT relay Rated insulation voltage 250 VAC (rms) Contact Ratings (AgSnO2)µ Resistive loadsAC 1 5 A @ 250 VAC DC 125 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 132.5 A @ 24 VDC Mechanical life ≥ 30 x 106 operations Electrical life ≥ 105 operations (at 5 A, 250 V, cos ϕ = 1) Operating frequency< 7200 operations/h Dielectric strength Dielectric voltage 2 kVAC (rms) Rated impulse withstand volt. 2.5 kV (1.2/50 µs) Supply Specifications Power supply Overvoltage cat. II Rated operational voltage (IEC 60664, IEC 60038) through terminals: A1, A224 VDC ±15% and 24 to 240 VAC +10%/-15%, 45 to 65 Hz Voltage interruption ≤ 10 ms Rated operational power AC supply 4 VA DC supply 1.5 W Specifications are subject to change without notice (21.07.08)1 |
