Discover the superior quality and performance of the Carlo Gavazzi DCB01DM24 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DCB01DM24 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DCB01DM24 :
At Onrion LLC , we offer the DCB01DM24 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DCB01DM24 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | DCB01DM24 |
| Description | Timers |
| Internal code | ONR247949 |
| Weight | 1 |
| Technical specification | Timers Asymmetrical Recycler Types DCB01, PCB01 DCB01 PCB01 • Time range 0.1 s to 100h • 4 knob selectable functions Aa - Asymmetrical recycler ON first Ab - Asymmetrical recycler OFF first Sh - One shot time function Dt - Two state delay on operate (2 relays ver- sions only) • Selection of time range by DIP switches • Knob adjustable time setting Automatic start • Output: 1 or 2 x SPDT relay • For mounting on DIN rail in accordance with DIN/EN 50 022 or Plug-in • 22.5 mm Euronorm or 36 mm plug-in module housing • Combined AC and DC power supply voltage • LED indication for relay status and power supply ON Product Description Ordering key DCB 01 C M24 Combined function timer with asymmetrical recycler, one shot time and two state delay on operate functions. Individ- ual selection of the time ranges from 0.1 s to 100 h. For mounting on DIN-rail (DCB01) or Plug-in (PCB01). Housing Function Type Item number Output Power Supply Type Selection Mounting Output Housing Supply: 24 VDC and 24 to 240 VAC Supply: 24 to 240 VAC/DC For DIN-rail 1 x SPDT D-Housing DCB 01 C M24 2 x SPDT DCB 01 D M24 Plug-in 1 x SPDT P-Housing PCB 01 C M24 2 x SPDT PCB 01 D M24 Time Specifications Output Specifications Time ranges Selectable by DIP switches 0.1 to 1 s 1 to 10 s 6 to 60 s 60 to 600 s 0.1 to 1 h 1 to 10 h 10 to 100 h Setting accuracy ≤ 5% Repeatability ≤ 0.2% Time variation (with respect to full scale value) Within rated power supply ≤ 0.2% - whole range Within ambient temperature ≤ 500 ppm/°C Reset Power supply interruption ≥ 200 ms Output 1 or 2 x SPDT relay Rated insulation voltage 250 VAC (RMS) Contact Ratings (AgSnO2) µ Resistive Loads AC 1 8 A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loads AC 15 2.5 A @ 250 VAC DC 13 2.5 A @ 24 VDC Mechanical life ≥ 30 x 106 operations Electrical life ≥ 105 operations (at 8 A, 250 V, cos ϕ = 1) Operating frequency < 7200 operations/h Dielectric strength Dielectric voltage 2 kVAC (RMS) Rated impulse withstand voltage 4 kV (1.2/50 µs) Specifications are subject to change without notice (19.06.07) 1 |
