Discover the superior quality and performance of the FEMA DCMV16 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DCMV16 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DCMV16 :
At Onrion LLC , we offer the DCMV16 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DCMV16 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply FEMA products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | FEMA |
| Product | DCMV16 |
| Internal code | ONR4752431 |
| Custom code | 85365080 |
| Technical specification | DCMV16 Alerton pressure switch for liquid, gas (DCM) For overpressure monitoring of non-aggressive liquids and gaseous media. Pressure type: overpressure, relative Pressure connection: internal thread G1/4, external thread G1/2 Electrical connection: DIN EN 175301 plug Protection class: IP54 Housing Material: Robust die-cast aluminum housing resistant to sea water GD Al Si 12. Media temperature: -25...70C Limit media temperature: Temperatures up to 85°C are permissible for short periods. Higher temperatures are possible provided the limit is protected by suitable measures (e.g. water pipe trap, see Accessories for Pressure Switches / Transmitters) Ambient temperature: -25...70C Room temperature. limit: at temperatures below 0 oC, make sure that no water condensation can occur on the sensor and switching device Switch Function/Capacity: SPDT Microswitch 250 Vac; capacity 5 A inductive, 8 A resistive Optional functions: add the type numbers below to the listed type numbers for extra functionality as described -301: terminal connection housing, IP65 -307: two microswitches, switching in parallel or in succession, fixed switching interval, terminal connection case, IP65 -217: two microswitches, 1 plug, successive switching, adjustable switching interval -213: gold-plated contacts, switching capacity: max. 24 VDC, 100 mA, min. 5Vdc, 2mA. And others not available with adjustable switching difference. -351: protection class IP65 and switch box with surface protection (chemical version) -513: gold-plated contacts, permanent switching differential, IP65, switching capacity: max. 24 VDC, 100 mA, min. 5Vdc, 2mA; adequate isolation switching amplifier, Ex-i degree of protection adjustable pressure hysteresis Pressure adjustment range: 3...16bar Adjustable switching differential: 0.7...3.5bar Switching differential: no max. pressure: 25 bar Sensor element material: 1.4104 + 1.4571 |
