Discover the superior quality and performance of the Warex DKZ 110 APS / DN 200 (5146.APS) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DKZ 110 APS / DN 200 (5146.APS) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DKZ 110 APS / DN 200 (5146.APS) :
At Onrion LLC , we offer the DKZ 110 APS / DN 200 (5146.APS) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DKZ 110 APS / DN 200 (5146.APS) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Warex |
| Product | DKZ 110 APS / DN 200 (5146.APS) |
| Internal code | ONR4062532 |
| Custom code | 84818085 |
| Technical specification | for medium: Bulk Feature: free-flowing, chemically neutral, not prone to bake Working pressure: < 0.5 bar Max. operating pressure: < 0.5 bar (PS) MAWP (Note: MAWP = Auslprint) Operating Temp: 0°C to +150°C (Ts) MAWT Umgeb.-Temp: 0° C to +50° C (Ta) Ex protection: not required assessment of butterfly valves in accordance with PED 2014/68/EU, Diagram 7, certified module A2. The valves are not subject to conformity assessment. Butterfly valve, type DKZ 110 < APS > for clamping between flanges according to EN 1092, PN 10 Silumin casing Silicone Sealing Sleeve Red replaceable in the housing Can be pneumatically clamping against the flap disc < APS > Flap disc made of stainless steel 1.4408 with increased gap size Shafts made of stainless steel 1.4057 or higher quality Shaft sealing by means of O-rings Shaft Bearing in MS Socket Test pressure: design pressure x 1.1 bar for leaks DN 200 installation length: 54 mm AT150 with pneumed pneum. Rotary actuator Type: AT 150. DR - double acting Required control pressure: 6 bar 444ee el./peum Control for APS flaps ** 1 signal control el./pneum. Control for butterfly valves Type: DKZ 110/103 and DKZE < APS > for opening and closing butterfly valves of the series < APS > and simultaneously Control of pressurization of the pressurization of the Sealing collar, comprising: 1 x 5/2-way solenoid valve, Mb.: Norgren Herion Type: 2623077.3037 Voltage: 24 V DC 2 pieces exhaust air choke valves for solenoid valve 622a with 2 pcs proximity initiators, Mb.: P+F, Type: NBN 4-12GM50-E2 pnp, with LED yellow, 10... 30 V DC Installed in plastic casing + wired according to terminal diagram a5446 incl. Namur Console 1 piece pneum. PWS-C5149 Parker Pressure Switch 1 mounting plate for Namur valve 1 quick air vent valve L-SEV-1/4 mSV (from DN 350, two quick air vent valves) 1 piece pressure regulator incl. pressure gauge 0-10 bar Includes necessary screw connections and lanyards Execution according to tax plan 0003475h |
