Discover the superior quality and performance of the Interroll DM1133-AAC13B0E8JDJ-307mm with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DM1133-AAC13B0E8JDJ-307mm is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DM1133-AAC13B0E8JDJ-307mm :
At Onrion LLC , we offer the DM1133-AAC13B0E8JDJ-307mm at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DM1133-AAC13B0E8JDJ-307mm ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Interroll |
Product | DM1133-AAC13B0E8JDJ-307mm |
Internal code | ONR4947277 |
Technical specification | MI-DM0113 Product name DM 0113 3-phase asynchronous Protection level IP 69K Tube length (SL) 300.0 mm Drum width (FW) 307.0 mm Installation length (EL/LW/BF) 320.0 mm Overall axle length (AGL) 370.0 mm Power 225 W coil number of poles 2 Torque [Nm] 21.1 Band tensile force 371 N Gear ratio (i) 30.00 Transmission Material description Cast iron: GGG-40 Speed at frequency 1 0.55 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.56 A rated current, low voltage 0.96 A Speed at frequency 2 0.65 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Pipe diameter (A) 113.5 mm Pipe diameter (B) 112.0 mm Convex tube shape (standard) Cover A version Standard cover B version Standard Cover A Material stainless steel: 1.4301/304 Cover B Material stainless steel: 1.4301/304 Shaft A version standard Ø25mm shaft B version standard Ø25mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Wave A key area (F) 20.0 mm Wave B key area (F) 20.0 mm Wave A key face length (C) 25.0 mm Wave B key face length (C) 25.0 mm Oil type synthetic food oil Electrical connection straight screw connection Elek. Connection material stainless steel: 1.4301/304 Power cable length 5.0 m Power cable type shielded; not halogen-free |
