Discover the superior quality and performance of the Interroll DM 0138 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DM 0138 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DM 0138 :
At Onrion LLC , we offer the DM 0138 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DM 0138 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Interroll |
Product | DM 0138 |
Description | asynchronous 3-phase |
Internal code | ONR4601132 |
Technical specification | MI-DM-SPECIAL 000000000061120520-316mm Product name DM 0138 asynchronous 3-phase Description HO-ACC with mounted flange IP 69K degree of protection Tube length (SL) 300.0 mm drum width (FW) 316.0 mm Installation length (EL/LW/BF) 336.5 mm Axle total length (AGL) 386.5 mm power 550 W winding number of poles 2 Torque [Nm] 104.3 tape tension 1,512 N Transmission ratio (i) 63.00 velocity at frequency 1 0.33 m/s frequency 1 50 Hz high voltage 400 V velocity at frequency 2 0.40 m/s frequency 2 60 Hz high voltage 2 460 V Pipe description - Pipe material steel: St37-2/AISI 1015 Pipe diameter (B) 138.0 mm Pipe diameter (A) 138.0 mm tube shape cylindrical lid description FLANGE MOUNTED ON HOUSING Lid A centring design Ø116-4x m8x12-PCD98 lid B version standard Lid A Material stainless steel: 1.4301/1.4307/304 Lid B Material ALU: EN-AC43400/AL239 Wave description - Shaft A Type Special Shank with 1 Face Ø30 Shaft B Design Special Shank with 1 Face Ø30 Shaft A material stainless steel: 1.4305/303 shaft B material stainless steel: 1.4305/303 Shaft A Diameter (D) 30.0 mm Shaft B Diameter (D) 30.0 mm Wave A final area width (F) 20.0 mm Wave B final area width (F) 20.0 mm Wave A final face length (C) 25.0 mm Wave B short face length (C) 25.0 mm oil type mineral oil Electrical connection straight screw connection Elek. Connection Material Brass CuZn39Pb3/MS58 power cable length 3.0 m power cable type shielded; not halogen-free |
