Discover the superior quality and performance of the Carlo Gavazzi ET1820-1 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ET1820-1 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ET1820-1 :
At Onrion LLC , we offer the ET1820-1 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the ET1820-1 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Carlo Gavazzi products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Carlo Gavazzi |
| Product | ET1820-1 |
| Description | Sensor |
| Internal code | ONR271056 |
| Weight | 1 |
| Technical specification | Photoelectrics Through-beam Type ET 1820 DC, Nickel-plated Brass Housing • Range: 20 m • Adjustable sensitivity • Modulated infrared light • Make and break switching functions, NPN, PNP (200 mA) • LED-indication for power supply ON (emitter) and target detected (receiver) • Supply voltage: 10 to 40 VDC • Heavy duty M18 metal housing, IP 67 • Cable and plug versions Product Description Ordering Key ET 18 20 NPA S-1 The ET1820 is a family of gen- eral purpose through-beam sensors in an industrial stan- dard M18 nickel-plated brass housing for heavy duty appli- cations. They are useful for simple applications where a basic sensor provide adequate sensing performance. The sen- sors are easy to adjust with a 270° single turn potentiometer. The output is a 4-wire comple- mentary (NO and NC) circuit with NPN (current sinking) or PNP(current sourcing) open collector transistor output. Type Housing diameter Range Output type Housing material Connection type Type Selection HousingRatedConnectionOrdering no. Ordering no.Ordering no. diameter operatingReceiver/NPN Receiver/PNPEmitter dist. (Sn)Make & break switching Make & breakswitching M18 20 mCableET 1820 NPASET 1820 PPAS ET 1820 M18 20 mPlug ET 1820 NPAS-1 ET 1820 PPAS-1ET 1820-1 Note: Please order emitter and receiver separately. SpecificationsEmitter Rated operational volt. (UB)10 to 40 VDC (ripple included) Ripple (Urpp) ≤ 10% Supply current (Io)≤ 20 mA ProtectionReverse polarity, short-circuits, transients Light sourceGaAIAs LED, 880 nm Light type Infrared, modulated Optical angle ± 2° Indication Supply ONLED, green Specifications Receiver Rated operating dist. (Sn)Up to 10 m Sensitivity270° single turn pot. meter Temperature drift0.6%/°C Hysteresis (H) (Differential travel) 3 to 20% Rated operational volt. (UB)10 to 40 VDC (ripple included) Ripple (Urpp) Max. 10% No-load supply current (Io) Max. 12 mA (typ. 8 mA) Min. operational current (Ie) 0.5 mA OFF-state current (Ir)Max. 100 µA (typ. 0) Output current Continuous (Ie) Max. 200 mA Short-time (I) 200 mA Max. load capacity 100 nF Voltage drop (Ud) Max. 2.5 VDC ProtectionReverse polarity, short-circuit, transients Optical angle ± 2° Ambient light Max. 5,000 lux Operating frequency (f)Typ. 170 Hz Response time OFF-ON (tON) Typ. 1.6 ms ON-OFF (tOFF)Typ. 4.2 ms Specifications are subject to change without notice (14.03.2006)1 |
