Discover the superior quality and performance of the Niezgodka F092961 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The F092961 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of F092961 :
At Onrion LLC , we offer the F092961 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the F092961 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Niezgodka products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Niezgodka |
Product | F092961 |
Internal code | ONR5010571 |
Custom code | 84814010 |
Technical specification | F092961 Safety valve with component mark and CE mark according to PED Valve type: 19.2 Model size: II Material: 1.4571/1.4581 do/Seat diameter: 25 mm Process connection: DIN 32676 clamp, for pipes in accordance with DIN 11866 series C Admission: DN/OD 2 Outlet: DN/OD 2 valve head: A Cone seal: PTFE (USP/ADI/FDA) other seals: EPDM (USP/FDA/ADI) Spring No.: 2490 Options: EGH Adjusted overpressure: 5.0 bar (g) Pressure level: PN 16 EGH: Surfaces in contact with media in the entrance area with surface quality Ra = 0.4 μm Medium: steam Temperature: 150°C Throughput: max 874 kg/h Clamp Dk: 64.0 mm Di connector: 47.5 mm Side length SE: 70.0 mm Side length SA: 70.0 mm Note: Custom made - no returns possible. The confirmed ADI seals include additional cleaning of the entire valve (free from animal ingredients and free of oil and fat). Then, on to the required A special lubricant (NSF-H1/ADI-free) is applied to areas. Note: Design as valve number F32461, but with spring according to the latest spring table Customs tariff number: 8481 40 10 Country of origin: DE |
