Discover the superior quality and performance of the Steimel ASF2-13RD-170833R with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ASF2-13RD-170833R is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ASF2-13RD-170833R :
At Onrion LLC , we offer the ASF2-13RD-170833R at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the ASF2-13RD-170833R ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | ASF2-13RD-170833R |
| Description | Gear pump |
| Internal code | ONR275044 |
| Weight | 1 |
| Technical specification | A-SF2/13RD-VLFM, pump unit, 2-20 bar 1.1kW, 1500, 230/400V, 50Hz, IP55, F, B5, IE3 Material number: 000.001.155.289 Gear pump unit: SF 2/13 RD - VLFM Product no.: ASF2-13RD-170833R Dimension sheet: DPA052D-170833R Spare part list: DET052013RD--165R Suction and pressure connection: G 1/SAE 1 Housing parts: EN-GJL-250 (GG-25) Sprocket shafts, noise-opti.: 16MnCrS5, egh., oblique Storage: multi-layer MD Shaft sealing: radial shaft seal Elastomers: FKM Pumping medium: lubricating oil Viscosity: 50 - 5000 cSt. Temperature: 10 - 60°C Flow rate: approx. 18.5/22.2 l/min. Pressure: 5 bar Speed: 1450/1740 rpm. pressure relief valve Opening pressure: 8 bar Adjustment range: 2-20 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Pump carrier with foot: BLF052200110LA21 Three-phase motor: LDM090-04-903 Motor data: Output 1/2:1.1/1.2 kW Speed 1/2:1500/1800 rpm. Voltage/frequency 1:230/400 volts at 50 Hz Voltage/frequency 2 265/460 volts at 60 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: primed Identification plate: ETY924-D-E---PE02 Installation: Pump rotated 90°, suction connection at the bottom (direction of pump base). Terminal box 90° to the left rotated (view of motor wave mirror) Motor type plate from the pressure side readable |
