Discover the superior quality and performance of the Fristam 0424000001 / FPE 722/150 A with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 0424000001 / FPE 722/150 A is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 0424000001 / FPE 722/150 A :
At Onrion LLC , we offer the 0424000001 / FPE 722/150 A at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 0424000001 / FPE 722/150 A ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Fristam products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Fristam |
| Product | 0424000001 / FPE 722/150 A |
| Description | centrifugal pump |
| Internal code | ONR4809545 |
| Custom code | 84137051 |
| Technical specification | pump with stainless steel cover and domes Pump material: 1.4404 (316L) Shaft seal: 9.468 (2V21E3) SIC/SIC/EPDM Elastomers: EPDM alcohol resistant with FDA certification Connector type: Tri-clamp Suction side: 2" Print side: 1.5" Impeller diameter: 150mm Engine: 2.2 kW, n = 2900 rpm 50 Hz, ISO class: F Voltage 230/400V IP 55 Funding dates: Product = Water solution Flow rate = 5 m³/h Differential pressure = 3 bar Viscosity = 1.5 - 1.6 mPa*s Certificates/ Exams: Documentation exclusively according to the Fristam standard, if not otherwise confirmed. - QH characteristic 1 operating point - Acceptance test certificate 3.1 in accordance with DIN EN 10204 - FDA certification/EC1935/2004 - Surface measurement report - certified measurement sheet In general: - pump with adjustment ring - Alexit No. 91 finish pure silver - Product contact surfaces for --> housing, cover, impeller, impeller nut <= Ra0.4μm engine: - Motor size IEC90L - Terminal box location: above - with PTC thermistor temperature sensor - according to efficiency class IE3 pump head: - with housing drain clamp (Ø12.70x1.65) - 90° bend forward with a view of the pump cover Shaft seal: - GLRD: simple other agreements: Certificate of Origin 2D & 3D drawing Pump is identical to S/No: 0424740125 |
