Discover the superior quality and performance of the Takex GT7SPN with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The GT7SPN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of GT7SPN :
At Onrion LLC , we offer the GT7SPN at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the GT7SPN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Takex products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Takex |
| Product | GT7SPN |
| Internal code | ONR2529256 |
| Weight | 0.1 |
| Custom code | 90275000 |
| Technical specification | Detection method Through beam Detecting distance 7m Detection object dia.6mm (oe more) Opaque Power supply 12-24V DC ±10％ / Ripple 10％ or less Current consumption Transmitter: 23mA or less Receeiver: 21mA or less Output mode Control output : PNP open collector output Rating: source current 100mA (30 VDC) or less Stability output : PNP output type does not have stability output Operation mode Light-ON/Dark-ON selectable (with switch) Response time 0.35ms or less Operating angle 10°(at receiver) Light source (light wavelength) Infrared LED (880nm) Indicator Transmitter: Power indicator (red LED) Receiver: Operation indicator (red LED) Stability indicator (green LED) Volume SENS: Sensitivity adjusment (on receiver for through-beam type) Switch Light-ON/Dark-ON selector switch provided Short circuit protection Provided (for control output only) Material Case : Polyarylate Lens : Polyarylate Connection Cable type (outer diameter: 3mm; length 2m) Transmitter: 0.15mm2 x 2 cores (gray) Receiver: 0.15mm2 x 3 cores (black)Accessories Mounting bracket, operation manual provided Environmental Specification Ambient light 5,000 lx or less Ambient temperature -25 - +55 ℃ (non-freezing) Ambient humidity 35-85%RH (non-condensing) Protective structure IP67 Vibration 10-55 Hz / 1.5 mm double amplitude / 2 hours each in 3 direction Shock 500 m/s2 / 3 times each in 3 directions Dielectric strength 1,000 VAC for 1 minute Insulation resistance 500 VDC, 20 MΩ or higher |
