Discover the superior quality and performance of the RTK Regeltechnik WENr.7092834-020 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The WENr.7092834-020 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of WENr.7092834-020 :
At Onrion LLC , we offer the WENr.7092834-020 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the WENr.7092834-020 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | WENr.7092834-020 |
Description | valve |
Internal code | ONR4032790 |
Technical specification | Repl. WENr.7092834-020 Motorized control valve - series MV 5211-K two-way design with emergency closing device nominal diameter DN 32, pressure rating PN 40 body made of stainless steel EN-GX5CrNiMo19-11-2 (1.4408) flanges with groove according to DIN 2512 spindle packing: chevron rings without nonferrous metal chloroprene characteristic / flow direction: linear / reverse V-port cone, soft sealing kvs-value = 15 m³/h, stroke 15 mm seat diameter 32 mm spindle heater: 2 x 10 W, 230 V, 50/60 Hz cauterized and passivated, without coating CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 100 °C valve according to DIN EN 12 284 leakage test according to DIN EN 12 266-1 Electric actuator - type REact 30E-074 actuating force 3 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.74 mm/s, stroke 15 mm protection rating IP 65 accessories: - emergency closing device ST 6151-5 + TÜV component mark closes at power failure (divert. v. port A, mix. v. port B) power supply solenoid valve 230 V, 50 Hz - with automatic start-up device RElog - anti-condensation heater 2 x 3 W, 230 V - additional limit switches (2 off) - potentiometer 1000 Ohm |
