Discover the superior quality and performance of the RTK Regeltechnik MV 5274, DN 32 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MV 5274, DN 32 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MV 5274, DN 32 :
At Onrion LLC , we offer the MV 5274, DN 32 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the MV 5274, DN 32 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK Regeltechnik products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK Regeltechnik |
Product | MV 5274, DN 32 |
Description | modulating valves |
Internal code | ONR4745012 |
Custom code | 84818059 |
Technical specification | Engine Control Valve - MV 5274 Series in three-way shape for mixing, with short B-flange Nominal diameter DN 32, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic/Anstrom.: linear/- mixing cone, metallic sealing Kvs value = 15 m³/h, stroke 15 mm seat diameter 32 mm Surface treatment with zinc dust primer CE mark in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 30E-074 actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm/s, stroke 15 mm Protection class IP 65 - additional limit switches (2 pieces) |
