Discover the superior quality and performance of the RTK MV 5314 control unit including actuator with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MV 5314 control unit including actuator is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MV 5314 control unit including actuator :
At Onrion LLC , we offer the MV 5314 control unit including actuator at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the MV 5314 control unit including actuator ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | MV 5314 control unit including actuator |
Description | control unit including actuator |
Internal code | ONR4941852 |
Technical specification | Replacement for W.Nr. 14082568/010 MV 5314 Series in continuous form nominal size DN 150, nominal pressure PN 16 Housing material: cast steel EN-GP-240-GH Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 292 m³/h, stroke 50 mm Seat diameter 125 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 60E-170 Positioning force 6 kN, including manual adjustment 230 V 50/60 Hz AC motor Adjustment speed 1.70 mm/s, stroke 50 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms - welded valve seat |
