Discover the superior quality and performance of the RTK PV 6211 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV 6211 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV 6211 :
At Onrion LLC , we offer the PV 6211 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PV 6211 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | PV 6211 |
Description | Pneumatic Control Valve |
Internal code | ONR4716704 |
Technical specification | in straight shape with ferro-titanit garnish Nominal diameter DN 15, nominal pressure PN 40 Housing material cast steel EN-GP-240-GH flanges with sealing surface in accordance with DIN Spindle sealing: Ferro-Titanite PTFE/carbon roof sleeves Curve/Anström.: equal percent/below the cone Parabolic cone made of ferro-titanite, metallically sealing Kvs value = 0.1 m³/h, stroke 25 mm seat diameter 4 mm Seatshell with ferro-titanite insert Surface treatment with zinc dust primer with certificate in accordance with EN 10204-3.1 max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 150 °C Pneumatic actuator - type ST 6115.C6-4S Inlet air pressure max. 6 bar Membrane area 120 cm² Spring range 0.8.. 2.4 bar/max. stroke 25 mm Safety position: spring closes (Distribution valve: Gate A, Mixing valve: Gate B Elektropneum. Position controller, type SR 6136 (SIPART PS2) 2/3/4 wire connection Input 4.. 20 mA at 0% input, valve closed - Position feedback module, 2-wire connection Output 4.. 20 mA (galvanically isolated) |
