Discover the superior quality and performance of the RTK PV 6314 / 20032586/040 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV 6314 / 20032586/040 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV 6314 / 20032586/040 :
At Onrion LLC , we offer the PV 6314 / 20032586/040 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PV 6314 / 20032586/040 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | PV 6314 / 20032586/040 |
Description | Pneumatic control valve |
Internal code | ONR4764689 |
Technical specification | two-way design nominal diameter DN 150, pressure rating PN 16 body made of spheroidal graphite iron EN-GJS-400-18-LT flanges according to DIN spindle packing: bellows seal with safety stuffing box PTFE/white characteristic / flow direction: linear / normal V-port cone, metal sealing kvs-value = 333 m³/h, stroke 40 mm seat diameter 150 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 350 °C Pneumatic actuator - type ST 6160.C6-7G air supply max. 6 barg diaphragm area 530 cm² spring range 0.7..3.0 bar / max. stroke 60 mm safety position: spring to close (diverting valve: port A, mixing valve: port B) accessories: - electropneumatic positioner, type SR 6136 (SIPART PS2) 2/3/4-wire connection input signal 4..20 mA at 0 % input, valve closed - module for position feedback, 2-wire connection output 4..20 mA (electrically isolated) - airfilter regulator with pressure gauge 10 bar, 1/4 NPT Ex ll 2Gc llC, -20 up to +70 °C (mounted on the positioner) Antrieb 20 mm vorgespannt Feder schließt gegen max. 2,5 bar |
