Discover the superior quality and performance of the RTK PV 6211 + ST 6135.B6-6G with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV 6211 + ST 6135.B6-6G is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV 6211 + ST 6135.B6-6G :
At Onrion LLC , we offer the PV 6211 + ST 6135.B6-6G at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PV 6211 + ST 6135.B6-6G ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | PV 6211 + ST 6135.B6-6G |
Internal code | ONR4818280 |
Technical specification | Pneumatic control valve - PV 6211 series in continuous form Nominal size DN 40, nominal pressure PN 25 Body material spheroidal iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: PTFE/carbon roof sleeves Curve/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 24 m³/h, stroke 30 mm Seat diameter 40 mm Surface treatment with zinc dust primer CE mark in accordance with the Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 250 °C Pneumatic actuator - type ST 6135.B6-6G Supply air pressure max. 6 bar membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (distribution valve: port A, mixing valve: port B) Column length 211 mm Surcharge for additional equipment |
