Discover the superior quality and performance of the RTK PV 6211 for 17082060/040 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PV 6211 for 17082060/040 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PV 6211 for 17082060/040 :
At Onrion LLC , we offer the PV 6211 for 17082060/040 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the PV 6211 for 17082060/040 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | PV 6211 for 17082060/040 |
Description | pneumatic control valve |
Internal code | ONR4902323 |
Technical specification | Pneumatic control valve - PV 6211 series in continuous form nominal size DN 25, nominal pressure PN 25 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: PTFE/carbon roof collars Characteristic/flow rate: equal percent/below the cone perforated cone, metallic sealing Kvs value = 4.8 m³/h, stroke 25 mm Seat diameter 20 mm Surface treatment with zinc dust primer max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 250 °C pneumatic actuator - type ST 6135.B6-6G Supply air pressure max. 6 barue Membrane area 280 cm² Spring range 0.8.. 3.0 bar/max. stroke 35 mm Safety position: spring closes (Distribution valve: port A, mixing valve: port B) additional equipment: - Electropneum. Positioner, type SR 6136 (SIPART PS2) 2/3/4-wire connection Input 4.. 20 mA at 0% input, valve closed - Position feedback module, 2-wire connection output 4.. 20 mA (galvanically isolated) |
