Discover the superior quality and performance of the RTK Repl. WENr.16072135-040 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Repl. WENr.16072135-040 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Repl. WENr.16072135-040 :
At Onrion LLC , we offer the Repl. WENr.16072135-040 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the Repl. WENr.16072135-040 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply RTK products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | RTK |
Product | Repl. WENr.16072135-040 |
Description | Pneumatic control valve - Model No. PV 6311 |
Internal code | ONR4247650 |
Custom code | 84818059 |
Technical specification | two-way design body size NPS 6", pressure class 300 ANSI body material carbon steel A 216-WCB Butt weld ends stem packing chevron rings PTFE/graphite characteristic: / flow direction: linear / under seat parabolic plug, stellited Cv value = 386 gpm, travel / stroke 2 3/8" seat diameter 6", stellited surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to ANSI B16.34 max. allowed temperature TS 482 °F Pneumatic actuator - type ST 6160.C6-7G air supply max. 6 barg diaphragm area 530 cm² spring range 0.7..3.0 bar / max. stroke 60 mm safety position: spring to open (diverting valve: port A, mixing valve: port B) accessories: - handwheel for manual operation - electropneumatic positioner, type TZID-C with HART (FKS-module) input signal 4..20 mA at 0 % input, valve closed - 3/2-way solenoid valve, G 1/4 power supply 230 V / 50 Hz - airfilter regulator with pressure gauge 10 bar, 1/4 NPT Ex ll 2Gc llC, -20 up to +70 °C (mounted on the positioner) (mounted on the actuator) |
