Home BernsteinP/N: 6081185009 Type: ENK-SU1Z AHS-V
P/N: 6081185009 Type: ENK-SU1Z AHS-V Bernstein

Buy P/N: 6081185009 Type: ENK-SU1Z AHS-V from Bernstein in United States


         Discover the superior quality and performance of the Bernstein P/N: 6081185009 Type: ENK-SU1Z AHS-V with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The P/N: 6081185009 Type: ENK-SU1Z AHS-V is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of P/N: 6081185009 Type: ENK-SU1Z AHS-V :

  • High Performance: Engineered to deliver exceptional results.
  • Durable Construction: Built with high-quality materials for long-lasting use.
  • Innovative Design: Incorporates the latest technology for enhanced efficiency.
  • Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the P/N: 6081185009 Type: ENK-SU1Z AHS-V at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

  • Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
  • Competitive Prices: We offer some of the best prices in the market.
  • Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
  • Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the P/N: 6081185009 Type: ENK-SU1Z AHS-V ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Bernstein products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

BRAND Bernstein
Product P/N: 6081185009 Type: ENK-SU1Z AHS-V
Description Plastic bodied limit switch
Internal code ONR1301416
Weight 0.23
Technical specification Series ENK Electrical Data Rated insulation voltage Ui 400 V AC Conv. thermal current Ithe 10 A Rated operational voltage Ue 240 V Utilization category AC-15, Ue/Ie 240 V / 3 A Direct opening action p acc. to IEC/EN 60947-5-1, annex K Short-circuit protective device Fuse 2 A gG Protection class II, totally insulated Mechanical data Enclosure Thermoplastic, glass fibre reinforced Cover Thermoplastic, glass fibre reinforced Actuator Turret head (Zn die-casting), roller (thermoplastic) Ambient air temperature -30 °C ... +80 °C Contact type 1 NC, 1NO (Zb) Mechanical life 10 x 106 operating cycles Switching frequency ≤ 100 / min. Assembly 4 x M5 Connection 4 screw connections (M3,5) Conductor cross-sections Solid: 0,5 ... 1,5 mm² or Litz wire with ferrules: 0,5 ... 1,5 mm² Cable entrance 1 x M20 x 1,5 Weight ≈ 0,23 kg Installation position operator definable Protection type IP65 acc. to EN 60529 ID for safety engineering B10d 20 x 10/6 cycles
