Discover the superior quality and performance of the Nord SK6382AFB-132SP/4 TF with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SK6382AFB-132SP/4 TF is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SK6382AFB-132SP/4 TF :
At Onrion LLC , we offer the SK6382AFB-132SP/4 TF at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the SK6382AFB-132SP/4 TF ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nord products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Nord |
Product | SK6382AFB-132SP/4 TF |
Description | Flat gear motor |
Internal code | ONR4721126 |
Technical specification | Product name flat gear motor Motor speed 1.465 rpm Translation 126.87 Output speed 12,000 rpm Operating factor 1.00 Output torque M2 (Nm) 4,548.00 Power (kW) 5,500 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Nominal current 1 (AMP) 10.90 Current Rating 2 (AMP) 6.29 Cosine 1 0.80 M4 gearbox design Housing type hollow shaft flange B5 Shaft size 70H7 Flange diameter (mm) 450 Open vent, with transport lock Viton gearbox oil seal Fastening element with fastening element Thermal motor protection cold conductor, 3x155°C Circuit type triangle Terminal box layer/cable insert 1/I Engine oil seal FKM (Viton) sealing ring Lubricant type Synth. ISO VG 220 oil CLP PG 220 oil grade Lubricant quantity (l) 18,000 Painting instructions Without painting CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Loose part fastener |
