Discover the superior quality and performance of the Ephy Mess 994190705000002 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 994190705000002 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 994190705000002 :
At Onrion LLC , we offer the 994190705000002 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 994190705000002 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ephy Mess products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Ephy Mess |
Product | 994190705000002 |
Description | Temperature sensor |
Internal code | ONR4265189 |
Custom code | 90259000 |
Technical specification | temperature sensor, transmission Metro Madrid 1Pt1000, 2 conductor circuit class B ±0.3 °C at 0 °C according to DIN EN 60751 connection head, brass, height=16mm dim.: Ø5xel=120.6mm, stainless steel, Mounting hole: for hexagon socket head screws M6 without plug, Feed line: shielded hose line 1x [4xAWG 24/7 cu silver-plated/STP/polyester film/cu tinplated/STP, KL=530mm, aø: 4.2mm] BK (RD/WH), Corrugated plastic pipe hose aø=13mm VCST-10B, 375 mm Measuring range ፦55°C... +155°C Ambient temperature ፦50°C... +105°C Insulation resistance: ≥ 200 MΩ/500 VDC screen placed on sensor housing Shield exposed on the connection side Halogen-free cable incl. polyamide corrugated pipe fitting M16 |
