Discover the superior quality and performance of the Rembe TCR-SGKKUB-3 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The TCR-SGKKUB-3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of TCR-SGKKUB-3 :
At Onrion LLC , we offer the TCR-SGKKUB-3 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the TCR-SGKKUB-3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rembe products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
BRAND | Rembe |
Product | TCR-SGKKUB-3 |
Internal code | ONR4161754 |
Custom code | 73269098 |
Technical specification | Artikel-Nr.: 31301221 Buckling bar reversible bursting disc with replaceable seal and integrated Signal transmitter for direct installation between Tri-Clamp flanges Medium in front of the rupture disc: liquid Nominal diameter (DN): 80 mm Relief area: 32 cm² Type of protection: overpressure Clamp standard: DIN 32676 Pipe standard: DIN 11866 C / ASME BPE Nominal size according to Pipe standard: DN / OD 3 '' Burst pressure: 1.03 bar g Burst temperature: 97 ° C Max. Permissible operating temperature: 150 ° C Lower burst tolerance: 10% Upper burst tolerance: 10% Vacuum resistance: absolute Buckling rod: ss316L Sealing part: ss316L Clamp seal: PTFE Clamp seal FDA certified: yes Clamp seal USP Class VI certified: yes Certification: factory burst certificate Test standard: AD 2000-Merkblatt A1 Special version: integrated signaling unit SGK: process remote '' Kapton '' insulated conductor Special version: with 1 m signaling cable, cable material: PTFE Dimensions: approx. 32x19x5 cm |
