Discover the superior quality and performance of the Steimel ATM6-110P-200674U with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ATM6-110P-200674U is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ATM6-110P-200674U :
At Onrion LLC , we offer the ATM6-110P-200674U at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the ATM6-110P-200674U ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Steimel |
| Product | ATM6-110P-200674U |
| Internal code | ONR4990252 |
| Technical specification | A-TM6-110P-GKGM pump unit GD, EC-eGH, AD+0.4.88 rpm, 2.2 kW, 230/400V, 50Hz, IP55, PTC, FL Gear pump unit: TM 6-110 P-GKGM with heating jacket horizontal installation position Item number: ATM6-110P-200674U Dimension sheet: DPA006M-200674U Spare parts list (Pump): DET006M-123121U Operating manual: DBA-ZP02 Suction and pressure connection: DN 40, PN 16 (DIN2633) Housing parts: EN-GJL-250 (GG 25) pinion shafts: 16 Mn Cr S 5, insert hardened, straight-toothed Shaft seal: stuffing box packing Storage: bronze AD increased storage air: 0.4 mm Bearing bush lubrication: grooves and holes Assembly note: CMH---CHOKO-01 Heating jacket: DN 15, PN 16 Conveying medium: chocolate mass Viscosity: assumed 3000-4000 cSt. Temperature: assumed 40°C Delivery rate: approx. 1,000 kg/h Pressure: 3-4 bar Speed: 88 rpm Direction of rotation: right and left with base plate (steel): EGP913060-24BB01 Gear motor documents: EUL---025200BB03 with coupling: BKUP118-2235-001 with clutch protection: EKS918140200BA80 Three-phase gear motor: LGMSK572---044 suitable for on-site FU operation Power: 2.2 kW Speed: 88 rpm Voltage: 230/400 volts Frequency: 50 Hz Protection class: IP 55 Insulation class: F with 3 cold conductors Design: B 3 Efficiency class: IE3 Special feature: motor with 230V external fan Special feature: gear oil for Food use Manufacturer: Getriebebau Nord Type: SK572.1-100LP/4 Installation position: M1 normal (horizontal) Terminal box location: 1 normal (on the fan seen on the left) Cable entry: I normal (down to the foot) Identification plate: ETY924-D-E--PE02 Painting: RAL 9006 |
