Discover the superior quality and performance of the Interroll DM0803-BAD1+H0E8GDH-200mm with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DM0803-BAD1+H0E8GDH-200mm is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DM0803-BAD1+H0E8GDH-200mm :
At Onrion LLC , we offer the DM0803-BAD1+H0E8GDH-200mm at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the DM0803-BAD1+H0E8GDH-200mm ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Interroll |
| Product | DM0803-BAD1+H0E8GDH-200mm |
| Description | motor |
| Internal code | ONR4831107 |
| Technical specification | Product name DM 0080 Asynchronous 3-phase Vertical drum motor design Protection grade IP 69K Tube length (SL) 193.0 mm Drum width (FW) 200.0 mm Installation length (EL/LW/BF) 229.0 mm Overall axle length (AGL) 254.0 mm Power 75 W Winding number of pins 2 Torque [Nm] 6.5 Tape tensile force 162 N Gear ratio (i) 26.94 Gear Material Name Steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.42 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.27 A rated current, low voltage 0.46 A Speed at frequency 2 0.53 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Stainless steel pipe material: 1.4301/304 Pipe diameter (A) 81.0 mm Pipe diameter (B) 81.0 mm Cylindrical tube shape Cover A version standard Cover B version standard Cap A Material Stainless Steel: 1.4301/ 304 Cap B Material Stainless Steel: 1.4301/ 304 Shaft A version Special shaft with 1 surface Ø30 Wave B version Special shaft with 1 surface Ø30 Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 Shaft A diameter (D) 30.0 mm Shaft B diameter (D) 30.0 mm Wave A closing area (F) 25.0 mm wave B closing area (F) 25.0 mm Wave A closing surface length (C) 12.5 mm Wave B closing surface length (C) 12.5 mm Oil type synthetic food oil Electrical connection straight screw connection elek. Connection material stainless steel: 1.4301/304 Power cable length 3.0 m Power cable type shielded; not halogen-free |
