Discover the superior quality and performance of the Bauer P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) :
At Onrion LLC , we offer the P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Bauer products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Bauer |
| Product | P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) |
| Description | Helical-geared motor |
| Internal code | ONR4004679 |
| Technical specification | Material number 30410781 BCAS item number 188P3185 Description BG06-31/D06LA4-TOF/UL-SP Item number: 188P3185 Helical-geared motor BG06-31/D06LA4-TOF/UL-SP Motor power: 0.25 kW Output shaft speed: 42.0 rpm Mount: B5 Terminal box position: II/D Corrosion protection: Standard Painting: unpainted Dimensional drawing: BG06 Catalogue: DG 07 Net weight per unit: approximately 9.5 kg Add.-/Special design: Output plate additional stamped with: Customer ID no. 207398 Total thickness of coating 0 µm Suitable for ambient temperatures from -10 to 60°C. Without terminal board (cable with end connector BAU2554194 connected to motor wires) Complete design in accordance with ZN.TEM151203-A3-1. Special cable motor in accordance with ZN.BAU2543478. MWN0543 Ölflex Quattro 7x0.75 mm² long with phoenix plug with hexagonal nut M20 BAU2532182 and O-ring BAU2525356 Special cable glands in accordance with ZN.BAU2580705. M20x1.5 MS Skintop Suitable for operation on static converter In the frequency range: 5 - 50 - 87 - 110 Hz Voltage: 30 - 133 - 230 - 230 V D Power: 0.016 - 0.25 - 0.445 - 0.51 kW Synchronous speed: 4.6 - 46.5 - 81 - 102 rpm Load moment: 34.0 - 56 - 56 - 50 Nm Load current approximately: 2.85 A Service factor: 0.8 Gear design: Type: BG06 2-staged helical gear Design Code 31 with standard flange on side front (d: 120 mm) Solid output shaft on gear side front (d: 17 mm) Total gear reduction i: 32.22 Add.-/Special design: Special gear housing in accordance with ZN.BG06-03-A2-AL-K3. M8 thread material. -No.: BAU2543443 Design of the motor: Type: three-phase squirrel cage motor D06LA4-TOF Rated speed: 1350 rpm Voltage: 133 V Connection: D Frequency: 50 Hz Rated current: 2.65 A Power factor cos phi: 0.69 Temperature class: F IP protocol type according to EN 60529: IP 65 IC cool. type EN 60034-6: IC 411 Terminal box: KAG2 Designed according to DIN VDE 0530-1/EN 60034-1 Add.-/Special design: With built-in thermostats “opening” for release Correlate to Insulation Class F via Supplemental Connection Diagram Z010.1030-13. Design of the motor acc. to UL file E220923 Fan made of special plastic B3 G5 ULTRAMID. Turn left when U-V-W is connected to L1-L2-L3 Terminal box design with terminal block State. Item no. 85015100 Country of origin Slovakia Operating manual DE Net weight 9,500 KG |
